Smile Sports Mini DV HD Car DVR Video Camera with MP3 function

1) 10m Audio Recording

2) Driving Records

3) Meeting Records

4) Monitor Records

5) PC Camera

6) MP3 function

* Functions summary:

1) Video Dimension: 640*480

2) Memory Support: 512MB/1GB/2GB/4GB/8GB (Optional)

3) Video Recording Function

4) Photo taking Function

5) PC Camera Function

6) USB: 2.0(Hs)

7) Built-in Li-Battery: Recording working 2 hours continuously (Max), MP3 working 4 hours continuously (Max)

8) Not need driver installation if the operating system is Windows ME/2000/XP/Mac OS 9.2.2or above (windows 98 is excepted)

9) Product Size: 48x48x16.62mm

10) Weight: 19g

* Charging

Built-in rechargeable Li-Battery, Please insert the USB cable to the DVR firstly. DVR firstly and then be in charging when the USB plug is connected with charger or inserted into the USB port of PC. Once connected correctly, the green light of this DVR will be in work. When green light is off and Blue light is on, which means the battery is in full capacity, then stop charging.

* Operation

1) ON/OFF

** Long press the button 1 for 3 second to turn it on, LED turns yellow, now standby. Long press button 1 for 3 seconds again to turn it off .if no any operation, after 10seconds, it will turn off automatically.

** Note: if the battery or the memory space is not enough to support, it will turn off automatically.

2) Video Record

** In the standby mode, short press the button 1,the yellow LED flash twice then put out, it will start to record .short press button 1 to save the video, meanwhile the blue light flash twice .when the yellow light on means it goes back to standby mode .

** Note: it will save the video and turn off automatically, if the memory and battery not enough to support.

3) Photo shooting

** In the standby mode, long press the button 2 to go into the photo shorting mode. short press button 2 to takes one photo, while the blue light flash one time. Long press the button 2 to exit the photo shooting mode, when the yellow light on.

4) MP3 Function

** In the standby mode, when you insert a earphone into this device ,it will start to play music. meanwhile the blue light flash slowly .

** NOTE: Before you play MP3, please make sure in the TF memory, the MP3 music files should be in the folder named "MP3"

5) Last/Volume

** In the MP3 Mode, short press Button 1 into last music, long press Button 1 into Volume+

6) Next/Volume-

** In the MP3 Mode, short press Button 2 into next music, long press Button 2 into Volume-

7) PC Camera (Webcam) without drive Function: when connect to USB port (can find "removable disk" in my computer) press Button 1; the DVR will transfer to webcam mode.

** Note: This function only support by windows 2000 and above, if your system can't install driver automatically, please check your system file.

8) Reset Key: Please press the Reset Key to restart when the player crash.
