Description
Features:
1) 100M high speed Ethernet card, Auto detected 10/100M High speed ethernet
2) Auto MDI/MDIX,Can use a crossover cable or parallel cable connection
3) RS232 bound rate can set up from 300 to 256000
4) RS485 bound rate can set up from 300 to 115200
5) Work mode: TCP Client, UDP mode, UDP Server mode; TCP Server mode
6) Support Virtual serial port
7) Across the gateway,across switches,routers
8) Can work in LAN,also can work on the Internet(external network)
9) Working port,destination IP address and port can be easily set up
10) Auto connect when in tcp mode, take a Safe and reliable link all the time
Specifications:
1) 32 bits ARM CPU
2) LAN:10/100Mbps;protect:Built-2KV isolated electromagnetic
3) RS232: TXD RXD GND
4) RS485: A(Data+)B(Data-);120 Ohms Termination Resistance on board
5) Network protocol:Ethernet ARP IP UDP TCP ICMP
6) Software tool:configuration software,TCP/UDP test soft,RS232 debug soft
7) Configuration method:RS232 or via Ethernet,free software avaliable
8) Power:5V
9) Size (L*W*H):90mm*50mm*18mm
10) Operating temperature: -25~75 °C
11) Preservation: -40~85 °C, 5~95%RH
1) 100M high speed Ethernet card, Auto detected 10/100M High speed ethernet
2) Auto MDI/MDIX,Can use a crossover cable or parallel cable connection
3) RS232 bound rate can set up from 300 to 256000
4) RS485 bound rate can set up from 300 to 115200
5) Work mode: TCP Client, UDP mode, UDP Server mode; TCP Server mode
6) Support Virtual serial port
7) Across the gateway,across switches,routers
8) Can work in LAN,also can work on the Internet(external network)
9) Working port,destination IP address and port can be easily set up
10) Auto connect when in tcp mode, take a Safe and reliable link all the time
Specifications:
1) 32 bits ARM CPU
2) LAN:10/100Mbps;protect:Built-2KV isolated electromagnetic
3) RS232: TXD RXD GND
4) RS485: A(Data+)B(Data-);120 Ohms Termination Resistance on board
5) Network protocol:Ethernet ARP IP UDP TCP ICMP
6) Software tool:configuration software,TCP/UDP test soft,RS232 debug soft
7) Configuration method:RS232 or via Ethernet,free software avaliable
8) Power:5V
9) Size (L*W*H):90mm*50mm*18mm
10) Operating temperature: -25~75 °C
11) Preservation: -40~85 °C, 5~95%RH
