Description
1) Frequency Range: 2.4~2.5GHz; Operating Voltage: 6~18V
2) Receiving Gain: 10dB ±1
3) Transmission Gain: 13dB ±1
4) Input Trigger Power: Min: 3dBm Max: 20dBm
5) Maximum Output Power (P1dB): 37dBm (5W)
6) EVM: 3%@29dBm 802.11g 54Mbps OFDM; 64QAM BW 20MHz
7) DC Supply Current: 575mA@Pout 29dBm 12V
8) Noise Figure: ﹤3.0dB; TX / RX Switch Time Delay: < 1 us
9) LED indicator: Transmitter: green; Receiver: red
10) Operating ambient temperature: -40~+70℃
11) Operating humidity: up to 95% rel. humidity
12) 20X the power, improving the link quality and coverage of certified WLAN devices
13) Working with certified IEEE 802.11 b/g/n wireless LAN devices
14) Simply plug and play, no software is required
15) Equipped with LED to indicate wireless
16) 3.0dB ultra-low noise
17) Wide 6V to 18V operating input voltage range
18) Dimension: 103.5mm x 96.5mm x 30.5mm; Weight: 0.4kg
2) Receiving Gain: 10dB ±1
3) Transmission Gain: 13dB ±1
4) Input Trigger Power: Min: 3dBm Max: 20dBm
5) Maximum Output Power (P1dB): 37dBm (5W)
6) EVM: 3%@29dBm 802.11g 54Mbps OFDM; 64QAM BW 20MHz
7) DC Supply Current: 575mA@Pout 29dBm 12V
8) Noise Figure: ﹤3.0dB; TX / RX Switch Time Delay: < 1 us
9) LED indicator: Transmitter: green; Receiver: red
10) Operating ambient temperature: -40~+70℃
11) Operating humidity: up to 95% rel. humidity
12) 20X the power, improving the link quality and coverage of certified WLAN devices
13) Working with certified IEEE 802.11 b/g/n wireless LAN devices
14) Simply plug and play, no software is required
15) Equipped with LED to indicate wireless
16) 3.0dB ultra-low noise
17) Wide 6V to 18V operating input voltage range
18) Dimension: 103.5mm x 96.5mm x 30.5mm; Weight: 0.4kg
